    Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material

    Ask Lasest Price
    Supply Ability : 10000PCS/Week
    Certification : CE/SGS/ISO9001
    Payment Terms : LC, T/T, D/P, PayPal, Western Union, Small-amount payment
    Price : negotiate
    • Product Details
    • Company Profile

    Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material

    Pneumatic Floating Ball Valve (Q41F)
    The ball and valve seat of the metal hard-sealed ball valve are completely metal-to-metal sealing. In order to ensure the reliable sealing of the valve under various temperatures and pressures, a variety of advanced ball and The hardening technology of the valve seat includes supersonic spraying, nickel-based spray welding, special surface hardening, cemented carbide spray welding and the use of high-strength and high-hardness ceramic materials.
    The surface hardness of the ball and valve seat can generally reach HRC60 or more, and the highest HRC74 and above. The temperature resistance of the sealing surface material can reach 540 ºC, and the maximum can reach 980 ºC.
    The bonding strength of the material can reach more than 10000PSI, and the sealing surface material also has good abrasion resistance and impact resistance. Metal hard-sealed ball valves are suitable for most harsh working conditions.


    Product NamePneumatic Floating Ball Valve(Q41F)
    1. MaterialStainless Steel WCB/304/316( CF8/CF8M)
    2. Size1/2"-12" ( DN15-DN300)
    3.CertificateISO9001 & CE
    4. PortNingbo/Shanghai
    5. Working PressurePN1.0-32Mpa
    6. Working Temp.-20ºC~200ºC
    7. SealA105+Carbide,F304+Carbide,F316+Carbide
    8. Locking handleOption
    9. Inspection& TestingAccording to API598
    10.Delivery Time15~20 Days
    11.Payment TermsT/T, Western Union, PayPal, etc.
    30% prepayment, 70% balance paid before shipping or against copy of BL
    12.Warranty12 Months after leaving factory
    13.OthersWe also manufacture High Platform Flange Ball Valve, Gate Valve, Globe Valve, Check Valve & Y Strainer
    Pneumatic Floating Ball Valve (Q41F)
    Pneumatic Floating Ball Valve (Q41F)



    Pneumatic Floating Ball Valve (Q41F) Pneumatic Floating Ball Valve (Q41F) Pneumatic Floating Ball Valve (Q41F) Pneumatic Floating Ball Valve (Q41F) Pneumatic Floating Ball Valve (Q41F)
    Company style
    Pneumatic Floating Ball Valve (Q41F)

    Pneumatic Floating Ball Valve (Q41F)

    Pneumatic Floating Ball Valve (Q41F)
    Company Honor
    Pneumatic Floating Ball Valve (Q41F)
    Pneumatic Floating Ball Valve (Q41F)
    Pneumatic Floating Ball Valve (Q41F)

    FAQ

    Q : Are you a factory or a trading company?
    A : We are a R & D factory.
    Q : Which country do you export to?

    A : We can export to any country according to buyer's need.
    Q : Do you accept the customized order?

    A : YES!


    Q : What is your main market?
    A : Southeast Asia, Middle East, North America, South America, Europe, etc.


    Q : Can you give me a discount?
    A: As you know, we are the manufacturer, so please trust us that our prices are competitive.
    If the quantity is large, we can consider giving you a discount.


    Q : If the product has quality problems, what will you do?
    A : We will be responsible for all quality problems.



    Q :What is your payment term?
    A :1.T/T, 30% down payment, balance paid before shipment.
    2. Letter of credit.


    Q: If the product has quality problems, what will you do?
    A: We will be responsible for all quality problems.
